8 Port Gigabit Ethernet 10/100/1000 Desktop PoE Switch + 2 Uplinks (SW80010-G-POE)
8 Port Gigabit Ethernet 10/100/1000 Desktop PoE Switch + 2 Uplinks (SW80010-G-POE)
The Dynamode SW80010-G-POE is a 8-Port Gigabit PoE (Power Over Ethernet) Switch Hub which allows users to instantly connect to PCs, Mac's and other network devices in an instant. Together with PoE on all 8 Ports means you can directly power PoE IP cameras, VoIP phones and other PoE devices without the need for separate power cables.
Complete compatibility and auto-sensing 10/100/1000Mbps in full and half duplex mode coupled, the SW80010-G-POE also comes with 2 dedicated uplink ports, so you can stack the switches together if you need too.
Energy efficient, ideal for work from home users, households and small offices that need an instant network connection.
Applications
Create additional Ethernet connections to your existing Switch,
Router in both home, SoHo and office LAN setups
Power-up PoE devices such as IP Cameras, VoIP phones etc without
the need for separate power cables
Branch and small offices needing faster networking connections
Key Features
Power-Over-Ethernet on all 8-Ports
Alloy construction - Desktop or wall mount
Plug n' Play – just connect to your existing Switch, Router etc
Silent and Reliable - Ideal for all your networking devices
Backed up by Dynamode's exclusive 3-year warranty
Product Code
Part Number: SW80010-G-POE
EAN: 84008000037671
Weight: 1.5 Kg approx
Technical Specifications
Compliance IEEE802, 802.3af, 802.3at
Port Power 16-30 Watts / 3-600mA, 48 Watts
Form Factor Compact Desktop or Wall Mount
Design RiSC chipset, store and forward
Uplink Ports 2-Ports dedicated uplinks
Duplex Control Full/Half Duplex and back pressure
Compatibility Cat5, Cat5e, Cat6, UTP and STP
Status LEDs 8-Port status for Link, Data etc
Power Supply Internal Switch Mode 110-240VAC
Supplied With
SW80010-G-POE 8-Port 10/100Mbps PoE Switch + 2 Uplinks
UK AC power cable
User guide
* Specifications and product design are subject to change. E&OE.
What's a LAN? Local Area Network is your wired Cat5e cabling for PCs, Printers, Servers, IP Cameras and other office Ethernet devices. The Switch can be securely mounted in a standard data cabinet with up to 10x the speed of Fast Switch
